SPEAKER, NEODYMIUM

Nominal Impedance: 8 Ohm
Minimum Impedance: 6.8 Ohm
AES Power Handling: 120 W
Maximum Power Handling: 240 W
Sensitivity (1W/1m): 97 dB
Frequency Range: 125-10000 Hz
Voice Coil Diameter: 37 mm (1.46 in)
Winding Material: Al
Former Material: Kapton
Winding Depth: 7.5 mm (0.30 in)
Magnetic Gap Depth: 6 mm (0.24 in)
Flux Density: 1.6 T
Magnet: Neodymium Ring
Basket Material: Aluminum
Demodulation: Aluminum Ring
Cone Surround: Half Roll
NET Air Volume filled by Loudspeaker: 0.38 dm^3 (0.013 ft^3)
Spider Profile: 1x constant height waves
