DS12000X4 Taramps Amplifier Module DS Class D (4 Channels 300 Watts RMS)

Operation Class: D
• Number of Channels: 04
• Maximum Power:
@ 12.6 VDC – 2 OHMS: 2000W RMS (4 x 500W RMS)
@ 12.6 VDC – 4 OHMS: 1250W RMS (4 x 312.5W RMS)
@ 12.6 VDC – 8 OHMS: 600W RMS (4 x 150W RMS)
Settings @ 12.6 VDC:
4 Channels: 4 x 500W RMS
3 Channels: 2 x 500W RMS + 1 x 1000W RMS – 4 OHMS Bridged
2 Channels: 2 x 1000W RMS – 4 OHMS Bridged
• Input Sensitivity: 250mV (Vol=max.)
• Signal to Noise Ratio: > 92dB
• Frequency Response: (Full Range): 20Hz to 36kHz (-1dB)
• High Pass Crossover (HPF): 80Hz ~ 2.2KHz (-6dB/8th)
• Low Pass Crossover (LPF): 80Hz(-12dB/8th)
• Bass Boost: 50Hz | 0 ~ 10dB
• Input Impedance: 22K OHMS
• Output Impedance: 2 OHMS
• Thermal Protection System and Short Output
• Minimum Supply Voltage: 8 VDC
• Maximum Supply Voltage: 16 VDC. ? ** Warranty information on the manufacturer’s website.
